The product that ships first

The Deterica Kit

A prosthetic hand costs more than a car and takes months to obtain. Nobody should have to buy one to find out whether this control model suits them. The Deterica Kit is designed to let a person explore that control without a prosthetic hand. A contact fork reads rotation of the residual limb, and an app shows the virtual hand.

The two halves do not arrive together. The app is built, and it needs no hardware: it runs on a phone alone, and a person can learn the control model on the screen. The kit is in development. It will connect to the same app, and then a movement of the contact fork will move the hand on the screen.

What the kit is for

The kit is designed to let a person explore the control through their own movement. The user places the residual limb between the two blades of the contact fork and rotates it around the sensor axis. The app shows the hand that follows. The contact fork design is recorded; physical fit and the complete assembly still need testing.

A prosthetic hand is a commitment of money and of months. So the order here is deliberate: try the control, and then decide. The app stays free, and it needs no kit. Nothing on this page is advice on the choice of a prosthesis. Speak to a prosthetist.

The kit

A contact fork, two buttons, one light

The contact fork turns with the residual limb. A sensor reads its angle, and calibration maps that angle to the opening and closing of the virtual hand. The control electronics can run the buttons, light, and calibration without a phone.

✓
USB-C powered. Version 1 has no battery
✓
Bluetooth Low Energy to the phone
✓
Calibration is stored on the kit and applied at power on
✓
The design must stay stable while the user rotates the contact fork

The app

The hand, on your phone

The app shows a virtual hand that responds to movement input. It runs with no kit at all: an on-screen slider and two buttons drive the same control logic, so anybody can try the model before a kit exists.

✓
Six grips: power grip, key, pinch, point, rock, hook
✓
Left hand or right hand
✓
Set your movement range with the kit buttons
✓
No account, and no server. Settings stay on the phone

The app

The hand on your phone, set up the way you want it

The app draws a prosthetic hand that exists, and it moves the way that hand moves. Move the on-screen slider and the fingers follow. Choose a grip and the hand takes it. Turn the hand over to look at the palm, and pinch to come closer.

✓
Six grips, one tap apart. Power grip, key, pinch, point, rock and hook. Next and Prev step through them, and the row of names marks the one you are in
✓
Your own colours. The hand, the finger pads and the buttons each take one of six colours. Choose them once, and the app opens that way every time
✓
Look at it from any side, and look inside. Drag to turn the hand over, tap the eye to make the housing see-through and watch the mechanism work, and tap twice to put it all back
✓
Left hand or right hand. One tap turns the whole hand over
✓
The same control rules. The app and kit use the same rules for opening, closing, and grip selection. The screen alone does not reproduce the physical experience

The Deterica Kit app on an iPhone: the hand, the row of six grips, a thumb slider, and the movement slider. — Control

The same app on the Appearance face: a black hand, white pads and white buttons, and a row of six colours for each. — Appearance

Get the app

Coming soon

The app is built and it works. It is not in the App Store yet. Write to us, and we will tell you the day it lands there.

Tell me when the app is out

Video

The hand it came from

The kit carries the control of a hand that exists. These are recordings of that hand.

Get it

The kit is not on sale yet

The control works and the electronics work. What remains is the mechanical part, and it is what decides the date. The hand behind it needs more than that again.

Get the kit

Coming soon

The control and the electronics work. The mechanical part is what remains, and it decides the date. Write to us, and we will tell you when the kit goes on sale.

Tell me when the kit ships
